First Look - United 2016 Complete Bikes

Treat yourself...

12 Jun 2015

2016 Martinez black side

Photos courtesy of United Bike Co

It's hard to believe but when United Bike Co started just over 9 years ago high quality complete bikes weren't that commonplace in BMX. Since then though and thanks to the likes of United and a bunch of our other DIG partners you can now head to local bike store and pick up the type of bike that you once could only have dreamed about building for yourself from scratch. The bikes are getting better better and they're being released earlier and earlier so here's a look at what United have to offer for their 2016 line-up.

Martinez FC red side

UNITED 2016 MARTINEZ EXPERT FC

1 - COREY MARTINEZ SIGNATURE LINE

2 - GOOD CLEARANCE FOR 2.4” TYRES

3 - 100% 4130 CROMO FRAME WITH REMOVABLE MOUNTS AND GUIDES

4 - INTEGRATED HEAD TUBE

5 - TOP TUBE & DOWN TUBE GUSSET WITH EMBOSSED LOGO

6 - 100% 4130 CROMO TAPERED FORKS WITH INTEGRATED BEARING RACE

7 - 100% 4130 CROMO 8.85” RISE BARS

8 - 175MM CROMO HEAT TREATED 3 PC CRANKS WITH STAMPED UNITED LOGO

9 - SEALED MID BOTTOM BRACKET

10 - UNITED VALENTINO NYLON PEDALS

11 - 14MM SEALED FREECOASTER HUB

12 - UNITED SUPREME 36H SEALED FEMALE BOLT FRONT HUB

13 - DOUBLE WALL 36H RIMS

14 - UNITED SUPREME 410X CHAIN

15 - 25T ALLOY UNITED SPROCKET

16 - UNITED FLANGELESS GRIPS

17 - UNITED SUPREME 52MM STEM

18 - UNITED MARTINEZ FAT PADDING TRIPOD SEAT

19 - UNITED DIRECT 2.4 TYRES FRONT AND REAR

20 - 4 X 100MM STEEL PEGS

2016 Martinez aqua side 2
2016 Martinez black side 2

UNITED 2016 MARTINEZ

1 - COREY MARTINEZ SIGNATURE LINE

2 - GOOD CLEARANCE FOR 2.4” TYRES

3 - 4130 CROMO DOWN TUBE

4 - INTEGRATED HEAD TUBE

5 - TOP TUBE & DOWN TUBE GUSSET WITH EMBOSSED LOGO

6 - TAPERED FORK LEGS WITH INTEGRATED BEARING

7 - 8.85” RISE BARS

8 - 170MM CROMO HEAT TREATED 3 PC CRANKS

9 - SEALED MID BOTTOM BRACKET

10 - UNITED VALENTINO NYLON PEDALS

11 - UNITED SUPREME 14MM 4 PAWL FULLY SEALED REAR CASSETTE HUB

12 - 36H SEALED ALLOY FRONT HUB

13 - UNITED SUPREME 410X CHAIN

14 - 25T UNITED SPROCKET

15 - UNITED FLANGELESS GRIPS

16 - UNITED 50MM REACH TOP LOAD STEM

17 - UNITED MARTINEZ MID PADDING TRIPOD SEAT & POST

18 - UNITED DIRECT 2.4 TYRES FRONT AND REAR

19 - 2 X 100MM STEEL PEGS

2016 supreme transgreen side 1
2016 supreme transyellow side
2016 supreme clear side

UNITED 2016 SUPREME

1 - PRO LEVEL FRAME GEOMETRY

2 - IMPROVED FRAME AND FORK GEOMETRY AND FIT WITH 2.4” TYRES

3 - INTEGRATED HEAD TUBE

4 - DOWN TUBE GUSSET WITH EMBOSSED LOGO

5 - TAPERED FORK LEGS WITH INTEGRATED BEARING RACE

6 - 9” RISE BARS

7 - 170MM CROMO 3 PC CRANKS

8 - SEALED MID BOTTOM BRACKET

9 - UNITED VALENTINO NYLON PEDALS

10 - UNITED SUPREME 14MM 4 PAWL FULLY SEALED REAR CASSETTE HUB

11 - 36H SEALED ALLOY FRONT HUB

12 - UNITED SUPREME 410X CHAIN

13 - 25T UNITED SPROCKET

14 - UNITED JIMMY GRIPS

15 - UNITED 50MM REACH TOP LOAD STEM

16 - UNITED FAT SEAT/POST COMBO WITH CUSTOM SEWN PATCH

17 - UNITED DIRECT 2.4 TYRES FRONT AND REAR

2016 KL black side
2016 KL purple side
2016 KL teal side

UNITED 2016 KL 40

1 - NOW WITH 21" TT FOR TALLER RIDERS

2 - PRO LEVEL FRAME GEOMETRY

3 - INTEGRATED HEAD TUBE

4 - DOWN TUBE GUSSET WITH EMBOSSED LOGO

5 - TAPERED FORK LEGS WITH INTEGRATED BEARING RACE

6 - 8.5” RISE BARS

7 - 170MM CROMO 3 PC CRANKS

8 - SEALED MID BOTTOM BRACKET

9 - UNITED VALENTINO NYLON PEDALS

10 - UNITED SUPREME 14MM 4 PAWL FULLY SEALED REAR CASSETTE HUB

11 - 36H SEALED ALLOY FRONT HUB

12 - UNITED SUPREME 410X CHAIN

13 - 25T UNITED SPROCKET

14 - UNITED JIMMY GRIPS

15 - UNITED 50MM REACH TOP LOAD STEM

16 - UNITED COMBI SEAT WITH EXTRA PADDING

17 - AERO STYLE 36H FRONT RIM

18 - UNITED DIRECT 2.1” REAR TYRE

19 - UNITED INDIRECT 2.35” FRONT TYRE

2016 recruit jr groupshot2

UNITED 2016 RECRUIT JR

1 - IMPROVED FRAME AND FORK GEOMETRY AND FIT WITH 2.4” TYRES

2 - 18.5” & 20” TOP TUBE OPTIONS

3 - PRO LEVEL FRAME GEOMETRY

4 - DOWN TUBE GUSSET WITH EMBOSSED LOGO

5 - COLOUR MATCHED FRAME & HEADSET CUPS

6 - TAPERED FORK LEGS

7 - 165MM CROMO 3 PC CRANKS

8 - SEALED MID BOTTOM BRACKET

9 - IMPROVED ULTRA SLIM NYLON PEDALS

10 - FULLY SEALED 14MM CASSETTE HUB WITH 9T DRIVER

11 - UNITED SUPREME 410X CHAIN

12 - 20H SPOKED FRONT WHEEL/36H REAR

13 - 25T UNITED SPROCKET

14 - UNITED GRIPS & BAR ENDS

15 - NEW UNITED 50MM REACH TOP LOAD STEM

16 - UNITED DIRECT 20 X 2.1 REAR TYRE

17 - UNITED DIRECT 20 X 2.3 FRONT TYRE

18 - UNITED FAT SEAT/POST COMBO WITH CUSTOM SEWN PATCH

2016 recruit 18 groupshot

UNITED 2016 RECRUIT 18

1 - SCALED DOWN SLIM TUBING FRAME FOR LIGHT WEIGHT AND BETTER FIT

2 - TOP TUBE GUSSET WITH EMBOSSED LOGO

3 - PRO LEVEL FRAME GEOMETRY

4 - COLOUR MATCHED FRAME & HEADSET CUPS

5 - TAPERED FORK LEGS

6 - CAREFULLY SELECTED PARTS SET TO SUIT SMALLER RIDERS

7 - 140MM CROMO 3 PC CRANKS

8 - SEALED MID BOTTOM BRACKET

9 - JR SIZE NYLON PEDALS

10 - FULLY SEALED 10MM CASSETTE HUB WITH 9T DRIVER

11 - UNITED SUPREME 410X CHAIN

12 - 20H SPOKED FRONT WHEEL/36H REAR

13 - 25T UNITED SPROCKET

14 - UNITED JR SIZE GRIPS

15 - NEW UNITED 40MM REACH JR TOP LOAD STEM

16 - UNITED JR PADDED RAILED SEAT FOR EXTRA ADJUSTABILITY

17 - UNITED DIRECT 18 X 2.1 65 PSI TYRES

2016 recruit 16 groupshot

UNITED 2016 RECRUIT 16

1 - SCALED DOWN SLIM TUBING FRAME FOR LIGHT WEIGHT AND BETTER FIT

2 - DOWN TUBE GUSSET WITH EMBOSSED LOGO

3 - PRO LEVEL FRAME GEOMETRY

4 - COLOUR MATCHED FRAME & HEADSET CUPS

5 - CAREFULLY SELECTED PARTS SET TO SUIT SMALLER RIDERS

6 - CUSTOM ALLOY 127MM 3 PC CRANKS

7 - LOOSEBALL EURO BOTTOM BRACKET

8 - JR SIZE NYLON PEDALS

9 - FULLY SEALED 10MM CASSETTE HUB WITH 9T DRIVER

10 - UNITED SUPREME 410X CHAIN

11 - 20H SPOKED WHEELS

12 - 25T UNITED SPROCKET

13 - SMALL JR SIZE LEVER & GRIPS

14 - NEW UNITED 40MM REACH JR TOP LOAD STEM

15 - UNITED JR PADDED RAILED SEAT FOR EXTRA ADJUSTABILITY

16 - UNITED DIRECT 16 X 2.1 45 PSI TYRES
